Guards on Balconies and High Drops

Guard requirements are graded by consequence. A rail over a step down to a patio and a rail on a third-floor balcony are asked to do very different jobs, and the codes reflect that with thresholds tied to the drop below.

Cross one of those thresholds and several things change at once. The guard gets taller, the load it has to resist goes up, and the details that were fine on a low deck stop being acceptable.

Measure the drop before designing the guard. That measurement decides everything downstream of it.

What changes as the drop grows#

Climbability is the one people argue about. A horizontal rail in the middle of a guard is a ladder for a small child, and over a long drop the codes stop treating that as an aesthetic choice. Designs that put the structure on the outside and keep the inside face smooth are the usual answer.

The load requirement is the change that catches builders out, because it is invisible. A guard that looks identical to one on a ground-level deck can be required to resist several times the force, and nothing about the appearance tells you which one you are looking at. That difference lives in the post spacing, the hardware and the connection rather than in what shows.

Balconies bring their own problems#

A balcony guard is attached to the building rather than to a freestanding deck frame, and that connection passes through the exterior envelope. Every fastener is a hole in a weather barrier that is holding back rain and, on a high wall, wind-driven rain at that.

Water getting in at balcony connections is one of the more common serious envelope failures in Canadian multi-unit buildings, and the repairs are expensive because the damage sits inside the assembly for years before it shows.

The other thing a balcony guard has to contend with is wind. High above grade a solid or glass guard catches load the same way a sail does, and that load goes straight into the same connections already carrying the code-required lateral force. Solid infill panels on an exposed elevation are a case for engineering rather than for judgement.

1. 1

   Measure the drop at the worst point

   Sloping ground means the drop varies along the edge. The largest measurement governs the whole guard.

2. 2

   Check the load requirement before choosing a system

   Many prefabricated guard systems are rated, and the rating has to cover the load your drop demands.

3. 3

   Detail the post connection

   Hardware, blocking and fasteners drawn rather than assumed. This is where guards fail.

4. 4

   Flash every penetration

   Anything bolted through a wall gets flashed and sealed as a deliberate detail, not caulked afterwards.

5. 5

   Confirm glass specifications in writing

   Glass guards have requirements about type, thickness and what happens if a panel breaks. Get the supplier to confirm against your local code.

Common questions#

Where exactly is the threshold?

It is a specific measurement in your provincial code, and several provinces have amended it. Look it up for your jurisdiction rather than carrying a number from another job.

Is my drop measured to grade or to the deck below?

To whatever surface someone would land on, at the worst point along the edge.

Can I use horizontal cable railing?

Sometimes, and it depends on the jurisdiction and the drop. Cable systems also need enough tension to hold the opening limit, which requires stiff end posts.

Do I need an engineer for a balcony guard?

Frequently, particularly for the connection back to the building. Many prefabricated systems come with engineering for the guard but not for your attachment.

Does the load requirement apply to the infill too?

Yes. Pickets and panels have their own load requirement, separate from the one applied at the top of the guard, and a system can satisfy one while failing the other.

What about an existing balcony being reclad?

Once the guard is removed and reinstalled it is generally treated as new work under the current code. That is often the moment a building discovers its guards were never adequate, and it is a common source of unbudgeted cost in a restoration project.
